Beryllium copper that is used for designing the Beryllium Copper Round Bar is also called as beryllium bronze or copper-beryllium or spring copper. This is a copper alloy that is having copper with 0.5-3% of beryllium alloy and often the other alloying compounds are too added into it. CuBe is containing the greater strength with the properties like non-sparking and non-magnetic. This alloy is having very good metalworking, machining and forming attributes. Also, it is having several specialized purposes in tools for the hazardous atmospheres, aerospace, precision measurement tool, etc. Also, this alloying element is presenting a toxic inhalation hazard at the time of manufacturing.

Specification of Beryllium Copper Rod

Specification

ASTM B441

Dimension Standard

AMS, ASTM, ASME

Size

custom diameter and sizes

Thickness

50 mm to 6000 mm Long

Length

Random, Fix, Custom Cut Length

Form

Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.

List Of Beryllium Copper Rod

Beryllium Copper Alloy 25 Rods Equivalent Grades

STANDARD

WERKSTOFF NR.

UNS

Alloy 25 (C17200)

2.1247

C17200

Beryllium Copper Chemical Composition

Element

Min/Max

Nominals

Al

0.2

-

Be

1.8 - 2.0

1.9000

Co

0.20 min

-

Cu

Rem

98.1000

Si

0.2

-

Beryllium Copper Alloys Physical Properties

Element

Beryllium Copper Alloys

Density

8.3 g/cc

Thermal Conductivity

0.3 cal/cm.cm²/s/°C

Electrical Conductivity

22% IACS

Softening Temp

300°C

Beryllium Copper Alloys Mechanical Properties

Element

Beryllium Copper Alloys

Tensile Strength (Min)

1050

Yield Strength (0.2%Offset) Min

850

Elongation %(Min)

2

Hardness HRC (Min)

35

Application Of Beryllium Copper Rod

Petrochemical Industry

Oil and Gas Industry

Chemical Industry

Power Plant Industry

Energy Industry

Pharmaceuticals Industry

Pulp & Paper Indusry

Food Processing Industry
